180ﾟ Type
-
LP/H127SGN a A b -1xXX 1.27mm Pin Header H:1.0 W:2.1 Single Row Straight DIP Type
Specifications
- Current rating : 3A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000 Megohms Min.
- Operating Temperature : -40°C to +85°C (PBT), -55°Cto +105°C (NYLON 6T)
Material
- Contact : Coppery Alloy
- Insulator : Polyester,UL94V-0, NYLON 6T or PBT
- Plating : All Gold or Tin
-
LP/H127SGN a A b -2xXX 1.27mm Pin Header H:1.0 W:3.4 Dual Row Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
-
LP/H127SGN a B b -2xXX 1.27mm Pin Header H:1.5 W:3.4 Dual Row Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
-
LP/H127SGN a A c A b -1xXX 1.27mm Pin Header H:1.0 W:2.1 Single Row Dual Base Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
-
LP/H127SGN a A c A b -2xXX 1.27mm Pin Header H:1.0 W:3.4 Dual Row Dual Base Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
-
LP/H127SGN a E c E b -1xXX 1.27mm Pin Header H:2.5 W:2.1 Single Row Dual Base Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
-
LP/H127SGN a E c E b -2xXX 1.27mm Pin Header H:2.5 W:3.4 Dual Row Dual Base Straight DIP Type
Specifications
- Current rating : 1A
- Withstanding voltage : 500V AC
- Insulation resistance : 1000Megohms Min.
- Operating Temperature : -55°C to +105°C
Material
- Contact : Coppery Alloy
- Insulator : NYLON 6T, UL94V-0
- Plating : All Gold or Tin
共計 7 項
