Product FFC/FPC Connectors 1.0mm Pitch FPC Series LFPCK810DL-SV-XX-PTX-X FPC 1.0mm H:2.8 NON-ZIF SMT Vertical Connector Normal&Reverse Type SPECIFICATION: Poles:4~30. Voltage rating:AC, DC, 50V(50HZ). Current rating: 0.4A, AC/DC. Withstand voltage:200V AC/minutes. Working Temperature:-25°C ~ +85°C. Insulation resistance:>500MΩ. Contact resistance:<0.02Ω. Terminal mtr'l:Phosphor Bronze. Housing mtr'l: PA9T,UL94V-0 Housing color: Black. PDF 請寫下你對於產品的建議然後點擊 加入詢價清單 以詢價 加入詢價清單 查看詢價清單 返回
