• Specifications

    Material

    • Insulator body (housing): PBT, UL94-V0, Color-Black.
    • Pin (outsleeve): Brass, machined, CuZn38pb2.
    • Tin plated: > 40u" nickel,100~150u" Tin Plated.
    • Clip (4 finger): Beryllium copper.
    • Gold plated: > 40u" nickel/full
    • Gold-flashed(0.4u"~1u").

    Electrical:

    • Current rating: 3 Amps / contact max.
    • Insulation resistance: > 1000 MΩ at V=100V.
    • Operating: 60 Veff.

    Mechanical:

    • Operating temperature: Gold plated: -55℃ to +125℃.
    • Tin plated: -40℃ to +105℃.
    • Soldering temperature: +200℃ 10s max.
